Machine working area:
X axis 3000mm
Y axis 1500mm
Z axis 115mm
Maximum workpiece weight:
1100 kg
Max. laser power:
10000 W
Speed simultaneously (X and Y):
280 m/min
Maximum sheet thickness:
Structural steel (O2) 30mm
Stainless steel (N2) 40mm
Aluminium alloy (N2) 25 mm
Copper (O2) 16mm
Copper (N2) 5mm
Brass (N2) 12.7mm
Accuracy:
Smallest programmable distance: 0.001 mm
Positional deviation Pa: 0.05 mm
Maximum position spread Ps: 0.03 mm
Control:
Siemens Sinumerik 840D SL
Main memory PC 4 GB
Colour monitor TFT touchscreen 21.5"
USB interface
Platform PC with Windows Embedded 7
Consumption values:
Cutting gases O2, N2: depending on the application
Laser cooling Closed cooling system
Entire system Electrical power consumption (incl. cooling unit):
8 - 47 kW
Compressed air consumption:
Average consumption 35 Nm³/h
Laser on hours (April 2023):
28400h
Cutting hours (April 2023):
10050h
