Auction description
Full Specifications
- Spindle: 40 hp Variable Spindle Speed with Inverter Drive
- Spindle Speeds: (rpm) 20 - 1300
- Spindle Bore: (mm) 160
- Spindle Nose: A2-11 camlock
- Speed Ranges: 2 Ranges High 40 - 1300 rpm & Low 20 - 415 rpm
- Spindle Taper: MT7 in bush
- Swing Over Bed: (mm) 780
- Swing in Gap: (mm) 1090
- Gap in front of Faceplate: (mm) 157
- Swing over Cross Slide: (mm) 535
- Distance between Centres: (mm) 3000
- Maximum Cutting Length: (mm) 2900
- Tailstock Travel: (mm) 200
- Tailstock Taper: MT6
- Tailstock Diameter: (mm) 105
- Bed Width: (mm) 500
- Ballscrews: X & Z
- Servo Motors: X & Z
- Floorplan (L x D x H): (mm) 5400 x 2300 x 2100
- Machine Weight: (kg) 8,600
- Air Requirements: 6 bar (220 L/min)
- Phase: 3
- Current: (amps) 67
- Volts: 400
